TPC-1581WP
15.6 WXGA TFT LED LCD Intel® 4th Generation Core i3 Multi-Touch Panel Computer
- Industrial 15.6 HD TFT LCD with 50K Lifetime LED Backlight
- Intel 4th Generation Core i3-4010U with 4GB DDR3L SDRAM
- 16:9 Wide Screen with PCT Multi-Touch
- IP66 Approved Front Protection & Panel Mounting
- Built-in Intelligent Home key and i Key for Intuitive UI
- Front LED Indicator to Show Operating Status
- Diverse system IO and Isolated Digital IO by iDoor Technology
- Supports Fieldbus Protocol by iDoor Technology
- 3G/GPS/GPRS/WiFi Communication by iDoor Technology
- Supports MRAM by iDoor Technology
- Chassis Grounding Protection
- HDMI and Audio Multimedia Support
- Anti-scratch surface: 7H hardness
Indent
Get Quote
Introduction
With growing up in Multi-Touch technology, the TPC-1581WP features Intel 4th Generation Core i3-4010U 1.7GHz processor with 4GB DDR3L SDRAM provides the high computing performance. To enhance reliability and durability, built-in 7H hardness anti-scratch surface on high resolution 15.6″ HD display with Multi-Touch in 16:9 format. Through the Mini-PCIe slot, Advantech iDoor technology can provide more I/O connectors, Isolated Digital IO, the Fieldbus Protocol, 3G/GPS/GPRS/WiFi Communication and MRAM. A 2nd monitor and speaker can be attached via the integrated HDMI and Audio port.
Specification
| Part Number | TPC-1581WP-433AE | |
| Display | Type | WXGA TFT LED LCD |
| Viewing Angle (H/V°) | 170/160 | |
| Backlight Life (hrs) | 50,000 hrs | |
| Luminance (cd/m2) | 300 | |
| Size | 15.6″ | |
| Max. Resolution | 1366 x 768 | |
| Max. Colors | 16.7M | |
| Contrast Ratio | 500:01:00 | |
| General | Power Consumption | 18W Typical, 60W Max. (Without Add-on card) |
| Power Input | 24VDC +/- 20% | |
| Watchdog Timer | 1 ~ 255 sec (system) | |
| Mounting | Panel Mount | |
| Certifications | BSMI, CCC, CE, FCC Class A, UL | |
| BIOS | AMI UEFI | |
| Cooling System | Fanless design | |
| OS Support | Microsoft® Windows WES7 32bit/64bit /WE8S 64bit/ Windows 7 32bit/64bit / Windows 8 64bit/Ubuntu 14.04.2 LTS/Windows 10 IoT Enterprise LTSB | |
| Weight (Net) | 6.0 kg (13.2 lbs) | |
| Enclosure Housing | Front bezel: Die-cast Aluminum alloy, Back housing: PC/ABS Resin | |
| Dimensions | 419.7 x 269 x 56.7 mm (16.52″ x 10.59″ 2.23″) | |
| System Hardware | CPU | Intel 4th Generation Core i3-4010U 1.7GHz |
| Memory | 4GB DDR3L 1600MHz SO-DIMM SDRAM | |
| Chipset | Lynx Point-LP | |
| LAN | 10/100/1000Base-T x 2 | |
| Expansion Slots | Full-sized Mini PCI-E x 1 | |
| I/O | RS-232 x1, RS-232/422/485 x 1, USB 2.0 x 2 (Host) | |
| Environment | Ingress Protection | Front panel: IP66 |
| Vibration Protection | With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration) | |
| Operating Temperature | 0 ~ 55°C (32 ~ 131°F) | |
| Storage Temperature | -20 ~ 60° C (-4 ~ 140° F) | |
| Humidity | 10 ~ 95% RH @ 40°C, non-condensing | |
| Touchscreen | Light Transmission | 0.88 |
| Resolution | 2048 x 2048 | |
| Type | Projected capacitive | |
