MIC-7700

Intel® 6th/7th Generation Core i Desktop Compact Fanless System
  • Intel® 6th/7th Generation Core i Desktop CPU (LGA1151) with Q170/H110 chipset
  • 2 x RS-232/422/485 and 4 x RS232 serial ports (with expansion cable)
  • 1 x 2.5″ HDD, 1 x CFast, 1x mSATA and 1 mini-PCIe with SIM
  • Supports 2 LAN, Isolation COM, 32-bit GPIO modules
  • 2 x GigaLAN and 8 x USB 3.0
  • VGA and DVI output
  • Supports Advantech’s i-module, SUSIAccess, and embedded software APIs
  • 9 ~ 36 V DC input power range
  • Wide operating temperature
Indent
Get Quote

Introduction

Specification

Part Number MIC-7700H-00A1 MIC-7700Q-00A1
Expansion Slot Mini-PCIE 1 x miniPCIe with USIM and 1 x mSATA 1 x miniPCIe with USIM and 1 x mini-PCIe/mSATA
Front I/O Interface USB2.0 4
USB3.0 4 8
Audio Jack 1xLine-out; 1x Mic-in 1xLine-out; 1x Mic-in
Serial Port 2xRS-232/422/485; 2xRS-232 2xRS-232/422/485; 2xRS-232
Environment Operating Shock With SSD: 20G, IEC-68-2-27, half-sine wave, 11 ms duration With SSD: 20G, IEC-68-2-27, half-sine wave, 11 ms duration
Operating Vibration 1Grms (with HDD), 3Grms (with SSD) 1Grms (with HDD), 3Grms (with SSD)
Ethernet Interface 2 x RJ-45 2 x RJ-45
Controller LAN1: Intel I219V, LAN2: Intel I210IT LAN1: Intel I219LM, LAN2: Intel I210IT
Graphics Graphic Interface VGA + DVI VGA + DVI
Chipset Integrated Intel HD Graphic 530/510, support DirectX12 Intel HD Graphic 530/510, support DirectX12
Miscellaneous Control Power Switch Power Switch
Physical Characteristics Dimensions (W x H x D) 78 x 192 x 230 mm 78 x 192 x 230 mm
Weight 2.8 kg (6.17 lbs) 2.8 kg (6.17 lbs)
Power Power Input 9-36VDC 9-36VDC
Power Type ATX/AT ATX/AT
Storage CFast 1 1
HDD 1 x internal 2.5″ HDD Bay 1 x internal 2.5″ HDD Bay
WatchDog Timer Interval Programmable 1 ~ 255 sec/min Programmable 1 ~ 255 sec/min
Output System Reset System Reset
Memory Max. Capacity 32GB (16GB per DIMM) 32GB (16GB per DIMM)
Socket 2 x 260-pin SO-DIMM 2 x 260-pin SO-DIMM
Technology Dual Channel DDR4-2133MHz Dual Channel DDR4-2133MHz
Processor System CPU Intel Core i3/i5/i7 (LGA1151) Intel Core i3/i5/i7 (LGA1151)
Chipset Intel H110 Intel Q170
Core Number 4 / 2 core 4 / 2 core
BIOS AMI 128Mbit SPI Flash AMI 128Mbit SPI Flash
Frequency Based on Intel CPU spec Based on Intel CPU spec
L3 Cache 8 MB/6 MB/4 MB/3 MB/2 MB 8 MB/6 MB/4 MB/3 MB/2 MB
