ADAM-6050
18-ch Isolated Digital I/O Modbus TCP Module
- 12-ch DI, 6-ch DO, Ethernet-based smart I/O
- Remote monitoring and control with mobile devices
- Group configuration capability for multiple module setup
- Flexible user-defined Modbus address
- Intelligent control ability by Peer-to-Peer and GCL function
- Active I/O message by data stream or event trigger function
- Multiple protocol support: Modbus TCP, TCP/IP, UDP, HTTP, DHCP
- Web language support: XML, HTML 5, Java Script
Indent
Get Quote
Introduction
ADAM-6000 accomplishes the integration of automation and enterprise systems easily through internet technology, so that users can avoid changing the entire architecture of the control system and even remotely monitor the device status more flexibly. ADAM-6000 modules are empowered by peer-to-peer (P2P) and Graphic Condition Logic (GCL), and can perform as standalone products for measurement, control and automation. Instead of having additional controllers or programming, system configurations can be done in
an extremely short time with the easy-to-use and intuitive graphic utility.
Specification
| ADAM-6050-CE | ||
|---|---|---|
| General | Description | 18-ch Isolated Digital I/O Modbus TCP Module |
| Display | LED Indicators | Status, Comm, Link, Speed |
| Power Supply | Power Requirement | 10~30 VDC |
| General | Watchdog Timer | System (1.6 second) & Communication (programmable) |
| Connector | 1 x RJ-45 (LAN) & 2 x plug-in terminal block (I/O and power) | |
| Temperature (Operating) | -20 ~ 70°C (-4 ~ 158°F) | |
| Humidity | 20~95 %RH | |
| Temperature (Storage) | -30 ~ 80°C (-22 ~ 176°F) | |
| Interface | 10/100Base-T(X) | |
| Peer-to-Peer | Yes | |
| GCL | Yes | |
| Isolation Protection | 2000 VDC | |
| Communication Protocol | Modbus/TCP, TCP/IP, UDP, and HTTP | |
| Communication Speed | Ethernet: 10/100Mbps | |
| Comm. Distance | Ethernet: 100 m | |
| Digital Input | Channels | 12 |
| Input Voltage | Dry contact: Logic level 0: close to GND Logic level 1: open Wet contact: Logic level 0: 3 VDC max. Logic level 1: 10~30 VDC | |
| Digital Output | Channels | 6 (Sink type) Open collector to 30V, 100 mA max. load Support 5 kHz pulse output |
